New Updated Furnace Control Board ICM282A Compatible for CEBD431012-01A, CEPL1311012-01, HK42FZ004, HK42FZ007, HK42FZ008, HK42FZ009, HK42FZ011,HK42FZ013, HK42FZ016, HK42FZ034, 325878-751

Restore your heating system to optimal performance with this professional-grade replacement furnace control board. Designed to replace a wide variety of older or defective Carrier, Bryant, and Payne furnace control boards, this unit utilizes advanced microprocessor technology to ensure precise ignition control and blower operation. It is the ideal solution for HVAC repairs and upgrades. Core Compatibility & Replacement Models This control board features extensive compatibility and serves as a direct replacement for the following OEM part numbers (please verify your original part number prior to purchase): HK42FZ Series: HK42FZ004, HK42FZ007, HK42FZ008, HK42FZ009, HK42FZ011, HK42FZ013, HK42FZ016, HK42FZ034 Other Numbers: 325878-751, CEPL1311012-01, ICM282, 1012-940, CEBD431012-01A Compatible Brands: Perfectly fits most Single Stage Gas Furnaces, including models from Carrier, Bryant, and Payne. Key Features and Benefits Microprocessor Precision: Built with a high-performance microprocessor to strictly monitor ignition timing, blower delays, and safety circuits. This offers superior reliability compared to traditional mechanical controls, ensuring consistent and stable heating. Comprehensive System Management: A single board effectively controls the gas valve, hot surface ignitor (120 VAC), inducer fan, blower motor (heating/cooling speeds), humidifier, and electronic air cleaner via standard 24V thermostat signals. Smart LED Diagnostics: Equipped with an onboard LED status indicator that provides clear feedback on system health. In the event of a malfunction, technicians can quickly identify issues (such as ignition failure or airflow problems) via the LED flash codes, saving valuable troubleshooting time. Enhanced Safety Protection: Features a 100% lockout safety function (automatically cuts off gas if ignition fails), along with reverse polarity protection and brownout protection, providing all-around safety for your equipment and home. Twinning Capability: Supports twinning functionality, allowing for the synchronized control of two matched furnaces in specific applications (requires compatible twinning setup). Technical Specifications Input Voltage: Line Voltage 98-132 VAC (60 Hz); Control Voltage 24 VAC. Relay Ratings: Supports standard residential HVAC loads for blowers, inducers, and ignitors. Mounting: Designed to match OEM standard dimensions and connections for easier installation. Important Notes Installation Recommendation: While this product is designed as a direct replacement, it involves high-voltage electricity and gas controls. For your safety and to ensure proper operation, professional installation by a licensed HVAC technician is strongly recommended. Pre-Purchase Check: Please double-check your existing control board model number and wiring terminals to ensure they match the compatible models listed in this description. This control board is a cost-effective solution for fixing heating system failures and extending the life of your furnace.

• This furnace control circuit board fixed speed furnace control replaces the following Carrier modules:CEBD431012-01A, CEPL1311012-01, HK42FZ004, HK42FZ007, HK42FZ008, HK42FZ009, HK42FZ011, HK42FZ013, HK42FZ016, HK42FZ034, 325878-751
• Features: Controls gas valve, ignitor, blower motor, inducer, humidifier and air cleaner. Microprocessor-based, designed for 100% gas shutoff in case of ignition failure.Reverse polarity protection, secondary brownout voltage protection, compatible with a 24 VAC standard thermostat ,provides diagnostic LED to aid in troubleshooting.
• Software for enhanced controls operation in counterflow and downflow furnace applications.Use caution when installing and servicing the furnace to avoid and control electrostatic discharge.
• Range: 98 to 132 VAC at 60 Hz Ignitor: 5A at 120 VAC. Cool Blower: 30A, 2 HP,240 VAC Heat: 5A, 1/2 HP, 240 VAC Inducer Motor: 4A, FLA-8.0 LRA at 120 VAC Gas Valve.
• Simple Installation with Wiring Diagram Included The ICM282A Furnace Control Board Designed for quick replacement without special tools. Comes with full cross-reference and wiring diagram. Please disconnect power and take photos of the old board before removal to ensure correct reconnection.
• Professional Guarantee & Support We stand behind our products with a 12-month After-Sale service. If you have any questions during installation or usage, feel free to contact us — we’re here to help.
